isoTEX® 620.A1 Heat protection blanket up to 1000 °C radiation heat
Heat Protection Blanket 620.A1
Type:
620.A1
Material specification:
E-Glass Fabric
Lamination:
A1 (One side Aluminum foil)
Weight:
1080 g/m²
Material thickness:
1.6 mm
Application temperature:
up to 1000 °C radiant heat
The isoTEX® 620.A1 heat protection blanket is manufactured from high-quality, air-texturized E-glass fabric with a unilateral aluminum foil. These heat protection blankets are characterized by their high heat reflection capability. The additional aluminum lamination can reflect up to 90% of incoming thermal radiation. Therefore, these heat protection blankets are ideal for safeguarding components, machinery, workpieces, and materials against high radiation temperatures up to 1000 °C. IsoTEX® 620.A1 heat protection blankets are non-flammable and can optionally be equipped with eyelets in various diameters as needed. Additionally, rolls of this material can be equipped with self-adhesive film on the back. The isoTEX® 620.A1 heat protection blankets are available in a variety of standard sizes as well as customized special sizes and can also be obtained as practical rolls.
We would be happy to advise you personally on this.
Heat Protection Blanket 620.A1
(up to 1000 °C)
Technical Specifications
| Material specification: | E-Glass Fabric |
| Application temperature: | up to 1000 °C |
| Lamination: | A1 (one side aluminum foil 10 µm) |
| Material thickness: | 1.6 mm |
| Weight: | approx. 1080 g/m² |
| Colour: | silver shiny |
| Standard fabric width: | 1000 mm |
| Versions: | Rolls, blankets with hemmed edges |
Technical Characteristics
- Application temperature up to 1000 °C radiant heat
- Kink resistant lamination
- Resistant to high radiation temperatures
- Good heat reflection
- Optionally with self-adhesive film on the back
- Non-flammable according to DIN 4102
- Solvent and halogen free
- Absolutely harmless to health, not subject to classification (NOT a hazardous substance)
Application Examples
- Heat protection blanket against radiant heat up to 1000 °C
- Heat-reflecting heat protection curtain
Product standard variants
Other versions and dimensions on request.
1) Click on the respective order number to start an inquiry about this article.
Rolls
| Widthmm | Roll lengthm | Weightkg | Order Number 1)- |
|---|---|---|---|
| 1000 mm | 50 m | 54,00 kg | 2062a0-010-500 |
Cutting service: Cuttings in rolls are possible; the minimum order quantity is 5.00 linear meters for cuts.
Blankets
| Dimensionsmm | Weightkg | Design- | Order Number 1)- |
|---|---|---|---|
| 1000 x 1000 mm | 1,08 kg | Blanket, hemmed | 2062a2-010-010 |
| 1000 x 2000 mm | 2,16 kg | Blanket, hemmed | 2062a2-010-020 |
| 1000 x 3000 mm | 3,24 kg | Blanket, hemmed | 2062a2-010-030 |
| 1600 x 2000 mm | 3,46 kg | Blanket, hemmed | 2062a2-016-020 |
| 2000 x 2000 mm | 4,32 kg | Blanket, hemmed | 2062a2-020-020 |
| 2000 x 3000 mm | 6,48 kg | Blanket, hemmed | 2062a2-020-030 |
| 2000 x 4000 mm | 8,64 kg | Blanket, hemmed | 2062a2-020-040 |
| 3000 x 3000 mm | 9,72 kg | Blanket, hemmed | 2062a2-030-030 |
| 3000 x 4000 mm | 12,96 kg | Blanket, hemmed | 2062a2-030-040 |
| 3000 x 5000 mm | 16,20 kg | Blanket, hemmed | 2062a2-030-050 |
| 3000 x 6000 mm | 19,44 kg | Blanket, hemmed | 2062a2-030-060 |
| 4000 x 4000 mm | 17,28 kg | Blanket, hemmed | 2062a2-040-040 |
| 4000 x 5000 mm | 21,60 kg | Blanket, hemmed | 2062a2-040-050 |
| 4000 x 6000 mm | 25,92 kg | Blanket, hemmed | 2062a2-040-060 |
| 5000 x 5000 mm | 27,00 kg | Blanket, hemmed | 2062a2-050-050 |
